너클 조인트 프레스 Barnaul KB8336 - 400 톤

Dabrox 매물 ID: 76350

이 오퍼에 대한 자세한 정보를 요청하세요:
- 재고 여부, 가격
- 지불/배송 조건
- 사양, 상태, 사진 등

* 필수 항목

Barnaul KB8336 너클 조인트 프레스 - 설명

너클 조인트 프레스 Barnaul KB8336 - 400 톤 (ID:76350)는 짧은 램 스트로크로 높은 힘을 발휘하는 너클 조인트 메커니즘을 갖춘 산업용 프레스입니다. 비교적 컴팩트한 설치 치수를 유지하면서 작업 사이클의 최종 단계에서 상당한 압력을 달성합니다. 짧지만 강력한 힘이 요구되는 코이닝, 캘리브레이션, 냉간 스탬핑 작업에 사용됩니다.

기술 사양 Barnaul KB8336 (ID:76350)

유형너클 조인트 프레스
제조사Barnaul
모델KB8336
Pressing force400 ton
Stroke130 mm
SPM50
Distance between a plate under a stamp and slider375 mm
Adjustment of the distance between the bolster plate and the slide12 mm
Table size500 x 500 mm
Voltage50 Hz, 380 V
Motor capacity12 kW
Machine dimensions1940 x 1240 x 2800 mm
Total weight8425 kg
